Power form: diesel
Approved load: 3.5 tons
Load center distance: 500mm
Standard lifting height: 3000mm, optional to 6000mm, with a lifting level every 500mm
Free lifting height: 155mm
Standard fork: length*width*thickness 1070*125*50, fork length can be optional 1220/1370/1520/1670/1820
Mast tilt: front 8/rear 10
Minimum turning radius: 2570mm
Minimum right-angle stacking channel width: 4045mm
Minimum right-angle channel width: 2770mm
Minimum ground clearance: 140mm in the middle of the frame (unloaded), 130mm in the lower end of the mast (unloaded)
Top guard height: 2090mm
Front overhang: 485mm
Maximum driving speed: fully loaded 19Km/h, empty 20Km/h
Maximum lifting speed: full load 430mm/s, no load 450mm/s
Maximum traction force: full load 28KN
Maximum climbing ability: 15%
Total length (without fork): 2810mm, full width: 1230mm, maximum lifting height of fork (with shelf) 4260mm
Mast height: 2075mm
Tire model: front wheel 28*9-15-14PR, rear wheel 6.50-10-10PR, wheelbase 1760mm
Wheelbase: front wheel/rear wheel 1000/970mm
Self-weight (no load): 4560KG
Battery: voltage/capacity 12V80AH
Engine: Model Xinchang 4D29V41, rated power 36.8Kw/2500r.p.m
Rated torque 156Kw/1700-1900r.p.m
Bore x stroke: 90mm*105mm
Number of cylinders: 4
Displacement: 2.67L
Fuel tank capacity: 55L
Working pressure: 18.5Mp
Tire type: standard pneumatic tires, optional solid tires
Number of wheels: front/rear 2/2
Full load descending speed: 330mm/s
No-load descending speed: 330mm/s
