Power form: lithium battery
Approved load: 2.5 tons
Load center distance: 500mm
Standard lifting height: 3000mm, optional to 6000mm, with a lifting level every 500mm
Free lifting height: 140mm
Standard fork: length*width*thickness 1070*125*40, fork length can be optional 1220/1370/1520/1670/1820
Mast tilt: front 8/rear 10
Minimum turning radius: 2500mm
Minimum right-angle stacking channel width: 3965mm
Minimum right-angle channel width: 2700mm
Minimum ground clearance: 110mm
Top guard height: 2060mm
Front suspension distance: 465mm
Maximum driving speed: fully loaded 14Km/h, empty 15Km/h
Maximum lifting speed: full load 300mm/s, no load 400mm/s
Traction force: 19KN
Maximum climbing ability: 15%
Total length (without fork): 2540mm, full width: 1160mm, maximum lifting height of fork (with shelf) 4030mm
Mast height: 1995mm
Tire model: front wheel 7.00-12-12PR, rear wheel 6.00-9-10PR, wheelbase 1665mm
Wheelbase: front wheel/rear wheel 970/970mm
Self-weight (no load): 3730KG
Battery: system voltage 80V, lithium battery capacity 150Ah, optional 175Ah, 230Ah, 280Ah
Motor: traveling 11KW, lifting 12KW
Control mode: AC
Working pressure: 18.5Mpa
Tire type: standard pneumatic tires, optional solid tires
Number of wheels: front/rear 2/2
