Driving mode: electric
Operating mode: walking
Rated load capacity: 1.5Q (t)
Load center: 600c (mm)
Front suspension distance: 944y (mm)
Wheelbase: 1243y (mm)
Weight (excluding battery): 142KG
Battery weight: 10KG
Tire type: Polyurethane
Driving wheel size∅*w(mm):∅210*70
Carrying wheel size∅*w(mm):∅80*60
Number of wheels, front/rear (x=drive wheels): 1x/4
Wheel base, load-bearing end bll (mm): 400/535
Lifting height h3(mm):200
Minimum/maximum height of handle lever in operating position h14 (mm): 740/1160
Minimum height of fork h13 (mm): 85
Vehicle length l1 (mm): 1630
Car body length 12 (mm): 453
Vehicle width b1/b2 (mm): 550/685
Fork size s/e/l(mm):50/150/1150
Fork outer width b5 (mm): 550/685
Ground clearance m2 (mm) at wheelbase center: 35
Channel width: 1000*1200 Pallet Ast(mm): 1804
Channel width: 800*1200 Pallet st (mm): 1854
Turning radius: Wa(mm):1398
Traveling speed, fully loaded/unloaded km/h: 4.2/4.5
Maximum gradeability: full load/no load %: 5/10
Braking type: electromagnetic braking, drive motor power KW: 0.75
Lifting motor power KW: 0.8
Battery voltage/capacity V/Ah:24/20
Battery weight KG: 6KG
Drive control type: DC speed control
Noise level (dB(A))<70
Steering type: mechanical steering
