Driving mode: electric
Operating mode: walking
Rated load capacity: 1.5Q (t)
Load center: 600c (mm)
Front overhang: 720x(mm)
Weight (excluding battery): 550KG
Battery weight: 2*27KG
Tire type: Polyurethane
Balance wheel size∅*w(mm):∅115*55
Number of wheels, driving wheels, balance wheels/carrying wheels: 1x+1/4
Wheel base, load-bearing end bll (mm): 400/535
Wheel base, drive end: b10 (mm): 522
Total vehicle height when the mast is at its lowest point: 1995mm
Lifting height h3 (mm): 3000, optional 1600/2000/2500/3300/3500/4000
Minimum/maximum height of handle lever in operating position h14 (mm): 740/1225
Minimum height of fork h13 (mm): 86
Vehicle length l1 (mm): 1740
Body length 12 (mm): 590
Vehicle width b1/b2 (mm): 795
Fork size s/e/l (mm): 60/160/1150
Fork outer width b5 (mm): 570/695
Ground clearance m2 (mm) at wheelbase center: 26
Channel width: 1000*1200 pallet Ast(mm): 2245
Channel width: 800*1200 Pallet st (mm): 2185
Turning radius: Wa(mm):1405
Traveling speed, fully loaded/unloaded km/h: 4.0/4.2
Maximum gradient: full load/no load %: 6/8
Lifting speed: full load/no load mm/s: 92/136
Descending speed: full load/no load mm/s: 112/98
Braking type: electromagnetic braking, drive motor power KW: 0.75
Lifting motor power KW: 2.2
Battery voltage/capacity V/Ah:2*12/100
Battery weight KG: 2*27KG
Drive control type: DC speed control
Noise level (dB(A))<69
Steering type: mechanical steering
