Drive mode: electric
Operation mode: stand-up type
Rated load capacity: 1.5Q (t)
Load center: 600c (mm)
Self-weight (including battery): 927KG
Battery weight: 130KG
Tire type: Polyurethane
Balance wheel size∅*w(mm):∅150*58
Number of wheels, driving wheels, balance wheels/carrying wheels: 1, 4/2
Wheel base, load-bearing end bl1 (mm): 390/515
Wheel base, drive end: b10 (mm): 646
Total vehicle height when the mast is at its lowest point: 2027mm
Lifting height h3 (mm): 3000, optional 1600/1800/2000/2600/3000/3200/3600/4000
Operating position handle lever minimum/maximum height h14 (mm): 1040/1415
Minimum height of fork h13 (mm): 86
Vehicle length l1 (mm): 1890
Body length 12 (mm): 740
Vehicle width b1/b2 (mm): 808
Fork size s/e/l(mm):60/180/1150
Fork outer width b5 (mm): 570/695
Ground clearance m2 (mm) at wheelbase center: 26
Channel width: 1000*1200 Pallet Ast(mm): 2380
Channel width: 800*1200 Pallet st (mm): 2360
Turning radius: Wa(mm):1495
Traveling speed, fully loaded/unloaded km/h: 5.5/5.2
Maximum gradient: full load/no load %: 3/6
Lifting speed: full load/no load mm/s: 135/100
Descending speed: full load/no load mm/s: 124/142
Braking type: electromagnetic braking, drive motor power KW: 1.5
Lifting motor power KW: 2.2
Battery voltage/capacity V/Ah: 24V/210AH
Drive control type: DC speed control
Noise level (dB(A))<70
Steering type: mechanical steering
